* 24/7 continuous long-range monitoring with the thermal ptz camera, capturing delicate, smooth details for precise observation. Equipped with a 2MP (1920x1080) daylight camera and 640x512 thermal camera, it ensures clear imaging in extreme conditions, making it a reliable thermal ptz camera.
* User-friendly design enables easy installation and rapid deployment, with all modules fully customizable to meet specific needs—enhancing the versatility of this thermal ptz camera.
* Integrated high-performance pan-tilt mechanism: 360° continuous pan rotation and -90°~+90° tilt for complete omnidirectional coverage. Boasting variable-speed control (Pan: 0.01~60°/s; Tilt: 0.01~30°/s) and ±0.1° preset accuracy across 200 presets, it delivers blind-spot-free, high-precision monitoring for the thermal ptz camera.
* Rugged IP66-rated enclosure with anti-corrosion materials and triple-proof treatment, built to withstand harsh environments: operating temperature -35℃~+65℃, <90%RH humidity, and 48-hour salt fog resistance (PH 6.5~7.2). It resists acid rain and corrosion, making this thermal ptz camera ideal for marine, coastal, and field scenarios.
* Enhanced dual-sensor sensitivity: Daylight camera with ultra-low light performance (Color: 0.001Lux @F1.5, AGC ON; B/W: 0.0005Lux @F1.5, AGC ON); thermal camera with 640x512 resolution, NETD ≤40, and 17μm spatial resolution—ensuring clear imaging in total darkness, fog, or glare for the thermal ptz camera.
1. The PTZ adopts a double-pitch worm gear transmission structure with low standby power consumption, featuring power-off self-locking, strong wind resistance, and stable operation—guaranteeing long-term reliability for the thermal ptz camera.
2. Sleek, rugged design with anti-corrosion properties, perfectly suited for harsh environments such as high-wind fields,
coastal areas, and industrial zones, enhancing the thermal ptz camera’s adaptability.
3. Equipped with continuous zoom thermal imaging technology (640x512 resolution, 100mm focal length) and 42X optical zoom (7-300mm) for the daylight camera, enabling wide-range target search and identification with the thermal ptz camera.
4. High-resolution thermal system with 640x512 pixels (optional 384x288), high temperature sensitivity (NETD ≤40), ensuring clear heat contrast for accurate detection in the thermal ptz camera.
5. Day-night dual-use daylight camera (1920x1080) with optional 4MP/8MP upgrades, supporting 22X-92X optical zoom to adapt to diverse monitoring ranges for the thermal ptz camera.
6. Multi-position intelligent recognition autofocus (auto/manual modes) adapts to scene changes (e.g., fog, motion) for fast, precise focusing—boosting the thermal ptz camera’s real-time response.
7. Advanced thermal imaging lens supports 200 customizable presets, with rotation speed automatically adjusted by zoom level, making the thermal ptz camera’s monitoring range control more intelligent and systematic.
8. Durable aluminum alloy PTZ shell with nitrogen filling, achieving IP66 waterproofing and resistance to salt spray (48-hour continuous spraying, PH 6.5~7.2), corrosion, and acid rain—ideal for marine environments, ensuring the thermal ptz camera’s longevity.
9. Compatible with multiple communication interfaces (TCP/IP, ONVIF, GB28181, etc.) with customizable protocols; integrates LRF, laser illuminators, and tracking modules for linkage tracking—expanding the thermal ptz camera’s functionality.
10. Universal variable-speed PTZ with 360° continuous pan, -90°~+90° tilt, and ±0.1° positioning accuracy, realizing blind-spot-free all-round monitoring—core to the thermal ptz camera’s high-precision performance.
Daylight Camera
* High-definition imaging: 2MP (1920x1080) resolution (optional 4MP/8MP) with 1/2.8” CMOS sensor, capturing sharp details even in ultra-low light (Color: 0.001Lux @F1.5, AGC ON; B/W: 0.0005Lux @F1.5, AGC ON).
* Flexible optical zoom: 42X optical zoom (7-300mm focal length) with optional 22X-92X ranges, perfectly matching the thermal ptz camera’s long-distance monitoring needs.
* Advanced image processing: Supports H.264/H.265 compression, 120dB WDR, optical defog penetration, and 3D noise
reduction—enhancing clarity in fog, backlight, or low-light conditions for the thermal ptz camera.
* Local storage: Supports 128G/256G SD cards for convenient data management, boosting the thermal ptz camera’s offline recording capability.
Thermal Camera
* Customizable thermal pixels: 384x288 / 640x512 / 1280x1024 (standard 640x512) to fit the thermal ptz camera’s precision requirements.
* Versatile lens options: 150mm, 200mm, 20-60mm, etc. (standard 100mm) for flexible long-range monitoring, adapting to diverse scenarios of the thermal ptz camera.
* Enhanced thermal performance: AGC automatic gain adjustment, 3D noise reduction, and SDE detail enhancement—paired with 8/15 adjustable pseudo-colors (black heat, white heat, etc.) for improved visibility in the thermal ptz camera.
* Seamless integration: Supports SDK & ONVIF protocols, ensuring compatibility with existing systems and enhancing the thermal ptz camera’s connectivity.
Laser Irradiator
* Integrated with the thermal ptz camera, this 8W 808nm laser source delivers 800-meter effective irradiation with strong
penetration, ensuring clear imaging in 0Lux full-dark environments.
* Works in sync with the thermal ptz camera’s high-resolution daylight/thermal cameras, using multi-core fusion uniform light technology to eliminate speckle/dark rings—enabling long-distance high-definition details for post-analysis.
* Equipped with an intelligent control system for remote adjustment of beam angle and intensity, automatically adapting to scenes to maximize the thermal ptz camera’s performance.
* Efficient heat dissipation and smart power management reduce energy consumption, prolonging service life and ensuring stable 24/7 operation alongside the thermal ptz camera. All laser modules are customizable for tailored needs.
